DRV8843EVM概述
TEXAS INSTRUMENTS DRV8843EVM 评估模块, 用于DRV8843
The is an evaluation module for DRV8843, a 2.5A, dual H-bridge motor driver with a PWM control interface and a small number external components that can be used to drive either two brushed DC motors, a single bipolar stepper motor, or four solenoids. The on board MSP430 MCU plus software/GUI supports signalling and control and PWM speed control. With the evaluation module, designers can quickly and easily evaluate the performance of DRV8843 motor driver in their specific application.
- .
- 2.5A Peak /1.75A RMS current output per bridge
- .
- Wide operating voltage from 8.2V to 45V
- .
- Low RDSON 400mR LS+HS
- .
- Four levels of on chip current regulation/cycle by cycle inrush protection
- .
- Supports 256 and greater microsteps with external voltage reference
- .
- Brake and coast modes supported
- .
- Thermal and short circuit protection
- .
- All critical control and status signals brought out to test headers
- .
- Includes a MSP430F1612 MCU for signalling and control
