CELDUC D31A3100 干簧继电器, D31A系列, SPST-常开, 5 VDC, 通孔安装, 500 ohm, 500 mA
The is a 1-pole Dual In-line Reed Relay with 1NO contact configuration, rhodium contact and through hole mounting, D31A series.
- .
- -40 to 70°C Operating temperature range
得捷:
REED RELAY 1A/5V
欧时:
单刀 - 常开 簧片继电器, 0.5A, 5V dc
e络盟:
干簧继电器, D31A系列, SPST-常开, 5 VDC, 通孔安装, 500 ohm, 500 mA
艾睿:
Reed Relay 5VDC 500Ohm 0.5A SPST-NO19.1x7.85x6.8mm THT Dry
Verical:
Reed Relay 5VDC 500Ohm 0.5A SPST-NO19.1x7.85x6.8mm THT Dry
Newark:
# CELDUC D31A3100 Reed Relay, D31A Series, 5 VDC, 500 ohm, 500 mA, 100 V, SPST-NO
触点类型 SPST-NO
接触电阻 150 mΩ
线圈电压 5 VDC
线圈电流 10 mA
线圈电阻 500 Ω
开断电压 100 V
线圈电压DC 5 V
开关电流Max 500 mA
工作温度Max 70 ℃
工作温度Min -40 ℃
接触电阻Max 150 mΩ
安装方式 Through Hole
引脚数 8
封装 DIP
高度 6.8 mm
封装 DIP
产品生命周期 Active
制造应用 Industrial, Automation & Process Control, 电源管理, 工业, 自动化与过程控制, Power Management
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
