TDK LAMBDA DPP120-48-1 交流/直流电源, DIN轨, 有源PFC, 固定/可调, 93 V, 264 V, 120 W, 48 V, 2.5 A
The is a 1-output 120W DIN rail-mount AC/DC Power Supply with adjustable and fixed output.
- .
- Parallel function switch
- .
- -40 to 71°C Operating temperature range
得捷:
AC/DC DIN RAIL SUPPLY 48V 120W
艾睿:
AC/DC Power Supply Single-OUT 48V 2.5A 120W 9-Pin
Allied Electronics:
Power Supply; AC-DC; 48V@2.5A; 93-132/186-264V In; Enclosed; DIN Rail Mnt; DPP Series
Chip1Stop:
AC/DC Power Supply Single-OUT 48V 2.5A 120W 9-Pin
Verical:
AC/DC Power Supply Single-OUT 48V 2.5A 120W 9-Pin
额定功率 120 W
输出接口数 1
输出电压 48 V
输出电流 2.5 A
输出功率 120 W
隔离电压 500 V
输入电压DC Max 370 V
输入电压DC Min 210 V
输入电压AC Max 264 v
输入电压AC Min 93 v
输出电流Max 2.5 A
输入电流Min 2.8 A
输出功率Max 120 W
工作温度Max 71 ℃
工作温度Min -40 ℃
输入电压AC 93V ~ 132V , 186V ~ 264V
引脚数 9
封装 120
长度 117 mm
宽度 2.5 in
高度 123.6 mm
封装 120
产品生命周期 Active
制造应用 Signal Processing, Power Management, 信号处理, 电源管理
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
ECCN代码 EAR99
