二极管与整流器
与整流器
立创商城:
60V 2A 560mV@2A
得捷:
DIODE SCHOTTKY 60V 2A POWERDI123
贸泽:
肖特基二极管与整流器 2.0A 60V HI EFFICNCY
艾睿:
If your circuit needs to adjust from an AC to DC voltage use a Schottky diode DFLS260-7 rectifier from Diodes Zetex. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. Its peak non-repetitive surge current is 50 A, while its maximum continuous forward current is 2 A. It is made in a single configuration. This rectifier has a minimum operating temperature of -65 °C and a maximum of 150 °C.
Allied Electronics:
2A 60V Schottky Rectifier PowerDI123
安富利:
Diode Schottky 60V 2A 2-Pin PowerDI 123 T/R
Newark:
# DIODES INC. DFLS260-7 SCHOTTKY RECTIFIER, 2A, 60V, POWERDI 123
儒卓力:
**SCHOTTKY-DIODE 60V 2A POWDI123 **
Win Source:
DIODE SCHOTTKY 60V 2A POWERDI123
针脚数 2
正向电压 620mV @2A
正向电流 2 A
最大正向浪涌电流(Ifsm) 50 A
正向电压Max 620 mV
正向电流Max 2 A
工作温度Max 150 ℃
工作温度Min -65 ℃
安装方式 Surface Mount
引脚数 2
封装 PowerDI-123-2
长度 2.8 mm
宽度 1.78 mm
高度 0.98 mm
封装 PowerDI-123-2
工作温度 -65℃ ~ 150℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
DFLS260-7 Diodes 美台 | 当前型号 | 当前型号 |
DFLS240L-7 美台 | 功能相似 | DFLS260-7和DFLS240L-7的区别 |
DFLS140-7 美台 | 功能相似 | DFLS260-7和DFLS140-7的区别 |
DFLS240-7 美台 | 功能相似 | DFLS260-7和DFLS240-7的区别 |
