Trans MOSFET N-CH 20V 0.54A Automotive 6Pin SOT-26 T/R
MOSFET - 阵列 2 N-通道(双) 20V 540mA 225mW 表面贴装型 SOT-26
得捷:
MOSFET 2N-CH 20V 0.54A SOT-26
艾睿:
This DMN2004DMK-7 power MOSFET from Diodes Zetex can be used for amplification in your circuit. Its maximum power dissipation is 225 mW. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This MOSFET transistor has an operating temperature range of -65 °C to 150 °C. This N channel MOSFET transistor operates in enhancement mode.
Allied Electronics:
Dual N-Channel Enhancement MOSFET SOT-26
安富利:
Trans MOSFET N-CH 20V 0.54A 6-Pin SOT-26 T/R
Verical:
Trans MOSFET N-CH 20V 0.54A Automotive 6-Pin SOT-26 T/R
儒卓力:
**2N-CH 20V 0,54A SOT26 **
Win Source:
MOSFET 2N-CH 20V 0.54A SOT-26
DeviceMart:
MOSFET DUAL N-CHAN 20V SOT-26
额定电压DC 20.0 V
额定电流 540 mA
通道数 2
极性 N-CH
耗散功率 0.225 W
输入电容 150 pF
漏源极电压Vds 20 V
连续漏极电流Ids 540 mA
输入电容Ciss 150pF @16VVds
额定功率Max 225 mW
工作温度Max 150 ℃
工作温度Min -65 ℃
耗散功率Max 225 mW
安装方式 Surface Mount
引脚数 6
封装 SOT-23-6
宽度 1.6 mm
封装 SOT-23-6
工作温度 -65℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
ECCN代码 EAR99
