KEMET EE2-3NU-L 信号继电器, EE2系列, DPDT, 3 VDC, 2 A, SMD, 非闭锁
The is a Miniature Signal Relay with DPDT silver alloy with gold alloy overlay contacts, non-latching coil, standard lead type and surface-mount terminals. This EE2-series relay features compact, lightweight and ultra-low profile with high density. Low power consumption and low magnetic interference.
- .
- Minimal board space
- .
- Extremely durable plastic sealing
- .
- High withstanding voltage
- .
- 140mW Nominal operating power
- .
- -40 to 85°C Ambient temperature range
额定电压DC 220 V
额定电压AC 250 V
额定电流 2 A
绝缘电阻 1000 MΩ
触点类型 DPDT
功耗 140 mW
触点额定电流 2 A
线圈电压 3 VDC
线圈电流 46.65 mA
线圈电阻 64.3 Ω
额定电流Max 2 A
线圈电压DC 3 V
线圈功率 140 mW
额定功率Max 60W, 125VA
开关电流Max 2 A
工作温度Max 85 ℃
工作温度Min -40 ℃
额定电压 250 VAC
额定电压DC Max 220 V
额定电压AC Max 250 V
接触电阻Max 75 mΩ
安装方式 Surface Mount
引脚数 8
封装 SMD
长度 15 mm
宽度 7.5 mm
高度 10 mm
封装 SMD
触点材质 Silver Alloy
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 消费电子产品, Communications & Networking, Security, 通信与网络, Test & Measurement, Consumer Electronics, 医用, Industrial, Medical, 音频, 安全, 测试与测量, Power Management, 工业, Automotive, Audio, 车用, 电源管理
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
