ET 系列 单刀双掷 开-开 PC 插针 通孔 密封 次微型 钮子开关
Use this sealed toggle switch from C&K Components as a way to toggle the power on one of your components. It has a SPDT configuration. This toggle switch has a minimum operating temperature of -30 °C and a maximum of 85 °C. The ET01LD1CBE toggle switch has a PC pin termination style. The maximum AC voltage rating is 20 VAC and the maximum DC voltage rating is 20 VDC. This product is 8.13 mm long, 21.52 mm tall and 5.08 mm deep.
触点电镀 Gold
额定电压DC 20 V
额定电压AC 20 V
绝缘电阻 1 GΩ
排数 1
额定功率 0.4 VA
触点类型 SPDT
工作温度Max 85 ℃
工作温度Min -30 ℃
额定电压 20 V
额定电压DC Max 20 V
额定电压AC Max 20 V
接触电阻Max <20 mΩ
安装方式 Through Hole
封装 -
长度 8.13 mm
高度 21.52 mm
封装 -
触点材质 Copper Alloy
工作温度 -30℃ ~ 85℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536509065
