ERZ-E07A201

PANASONIC ELECTRONIC COMPONENTS ERZ-E07A201 TVS Varistor, Surge Absorber, 130V, 170V, E7 Series, 340V, Disc 9mm, Metal Oxide Varistor MOV

变阻器 电路 通孔 圆片式 9mm

得捷:
VARISTOR 200V 2.5KA DISC 9MM

立创商城:
ERZ-E07A201

艾睿:
Provide proper variable resistance to your circuit by using this ERZ-E07A201 MOV from Panasonic. This device&s;s clamping current is 25 A and clamping voltage is 340 V. This part has a pitch of 7.5 mm. Its maximum surge current is 2500 A. This voltage dependent resistor has an operating temperature of -40 to 85 °C. This product comes packaged in bulk, so the parts will be stored loosely. This product is 12.5 mm tall and 5.3 mm deep with a diameter of 9 mm. Its capacitance value is 360pF. This varistor has a voltage of 200 V. The maximum AC voltage rating is 130 VAC and the maximum DC voltage rating is 170 VDC. This device utilizes metal oxide technology.

Verical:
Var MOV 130VAC/170VDC 2500A 200V Radial Bulk

Newark:
# PANASONIC ELECTRONIC COMPONENTS  ERZ-E07A201  TVS Varistor, Surge Absorber, 130 V, 170 V, E7 Series, 340 V, Disc 9mm, Metal Oxide Varistor MOV

MASTER:
Var MOV 130VAC/170VDC 2500A 200V Radial Bulk

Online Components:
Var MOV 130VAC/170VDC 2500A 200V Radial Bulk

Electro Sonic:
Var MOV 130VAC/170VDC 2500A 200V Radial Bulk
