STMICROELECTRONICS ESDA25W 静电保护装置, 排列, SOT-323, 3 引脚, 1.2 V, 400 W
The is a TRANSIL™ ESD Protection Array Device for data protection. It is designed to protect components connected to data and transmission lines against ESD. The device clamps the voltage just above the logic level supply for positive transients and to a diode drop below ground for negative transients.
- .
- 2 up to 5 Unidirectional Transil functions
- .
- <1µA Low leakage current
- .
- High ESD protection level up to 25kV
- .
- High integration
- .
- -40 to 125°C Operating temperature range
额定电压DC 25.0 V
工作电压 1.2 V
电容 65 pF
额定功率 150 W
击穿电压 25 V
电路数 2
针脚数 3
耗散功率 400 W
测试电流 1 mA
脉冲峰值功率 400 W
最小反向击穿电压 25 V
击穿电压 25 V
工作温度Max 125 ℃
工作温度Min -40 ℃
安装方式 Surface Mount
引脚数 3
封装 SOT-323-5
长度 2.20 mm
宽度 1.35 mm
高度 1.1 mm
封装 SOT-323-5
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 工业, Industrial, 通用, Communications & Networking, Wireless, 无线, 军用与航空, Computers & Computer Peripherals, 通信与网络, Aerospace, Defence, Military, 国防, 消费电子产品, Consumer Electronics, 计算机和计算机周边
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
军工级 Yes
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
