PANASONIC ELECTRONIC COMPONENTS ERJ8RSFR10V 电流感应电阻器, 表面安装, AEC-Q200 ERJ系列, 0.1 ohm, 250 mW, ± 1%, 1206 [3216公制]
1206 格式低电阻器 - 0.25W
ERJ 8R 芯片电阻器轻便紧凑。 这些芯片电阻器可提供高可靠性,由三层电极和金属上釉厚膜电阻元件制成。
符合 AEC-Q200
电流感应
小尺寸
低电阻值
适用于流动焊接和回流焊接
### 标准
IEC 60115-8, JIS C 5201-8, JEITA RC-2144
欧时:
### 1206 格式低电阻电阻器 - 0.25WPanasonic ERJ 8R 芯片电阻器轻便紧凑。 这些芯片电阻器可提供高可靠性,由三层电极和金属上釉厚膜电阻元件制成。符合 AEC-Q200 电流感应 小尺寸 低电阻值 适用于流动焊接和回流焊接 ### 应用这些电流感应电阻器符合 AEC-Q200 标准,可在汽车应用中使用。 ### 标准IEC 60115-8, JIS C 5201-8, JEITA RC-2144### 厚膜 - 1206
艾睿:
The ERJ-8RSFR10V fixed single surface-mount resistor from Panasonic makes it easy to add resistors to your circuit board. This product has a resistance value of 100m Ohm. This part has a power rating of 0.25 1/4 W. It is also complete with current sensing technology. Its temperature coefficient is ±250 ppm/°C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. It has a tolerance of 1%. This product is 3.2 mm long, 0.6 mm tall and 1.6 mm deep. This device utilizes thick film technology. This part has an operating temperature of -55 to 125 °C.
Newark:
# PANASONIC ELECTRONIC COMPONENTS ERJ8RSFR10V SMD Current Sense Resistors, AEC-Q200 ERJ Series, 0.1 ohm, 250 mW, - 1%
容差 ±1 %
额定功率 250 mW
产品系列 ERJ8R
电阻 0.1 Ω
阻值偏差 ±1 %
工作温度Max 125 ℃
工作温度Min -55 ℃
安装方式 Surface Mount
引脚数 2
封装公制 3216
封装 1206
长度 3.2 mm
宽度 1.6 mm
高度 0.6 mm
封装公制 3216
封装 1206
工作温度 -55℃ ~ 125℃
温度系数 ±250 ppm/℃
产品生命周期 Unknown
包装方式 Cut Tape CT
最小包装 5000
制造应用 工业, 车用, Industrial, Portable Devices, Sensing & Instrumentation, 便携式器材, 电源管理, Power Management, 传感与仪器, Automotive, 消费电子产品, Consumer Electronics
RoHS标准
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ERJ8RSFR10V Panasonic 松下 | 当前型号 | 当前型号 |
RL73K2BR10JTD 泰科 | 功能相似 | ERJ8RSFR10V和RL73K2BR10JTD的区别 |
WSL1206R1000FEA 威世 | 功能相似 | ERJ8RSFR10V和WSL1206R1000FEA的区别 |
CRL1206-FW-R100ELF 伯恩斯 | 功能相似 | ERJ8RSFR10V和CRL1206-FW-R100ELF的区别 |
