ERJ3EKF5102V

PANASONIC ELECTRONIC COMPONENTS  ERJ3EKF5102V  片式电阻器, 表面贴装, 厚膜, AEC-Q200 ERJ系列, 51 kohm, 75 V, 0603 [1608公制], 100 mW, ± 1%

0603 格式器，ERJ3EK 系列 - 1% 35.7Ω-196Ω

ERJ 3E 精密厚膜片式电阻器是紧凑、轻型解决方案。 这些片式电阻器由三层电极、金属釉厚膜电阻元件构成，非常可靠。 ERJ 3E 系列具有 ±1% 的低电阻容差，与自动贴片机兼容。 这些片式电阻器具有 AEC-Q200 资格，特别适用于汽车应用。

### 认可

IEC 60115-8，JIS C 5201-8，EIAJ RC-2134B

欧时:
Panasonic ERJ 系列 0.1W 51kΩ 精密厚膜SMD 电阻器 ERJ3EKF5102V, ±1%, ±100ppm/°C, 0603 封装

立创商城:
51kΩ ±1% 100mW

e络盟:
SMD片式电阻, 0603 [1608公制], 51 kohm, ERJ3EK Series, 75 V, 厚膜, 100 mW

艾睿:
This is a ERJ-3EKF5102V fixed single surface-mount resistor from Panasonic. This product has a resistance value of 51K Ohm. This durable part has a power rating of 0.1 1/10 W. Its temperature coefficient is ±100 ppm/°C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This part has an operating temperature of -55 to 155 °C. This device utilizes thick film technology. This product is 1.6 mm long, 0.45 mm tall and 0.8 mm deep. It has a tolerance of 1%.

安富利:
Res Thick Film 0603 51K Ohm 1% 1/10W ±100ppm/°C Molded SMD SMD Punched Carrier T/R

Newark:
# PANASONIC ELECTRONIC COMPONENTS  ERJ3EKF5102V  Surface Mount Thick Film Resistor, AEC-Q200 ERJ Series, 51 kohm, 100 mW, - 1%, 75 V
