EEEFK1E100R

PANASONIC ELECTRONIC COMPONENTS  EEEFK1E100R  铝电解电容, 表面贴装, AEC-Q200 FK系列, 10 µF, 25 V, Radial Can - SMD, 4 mm

FK 系列卷筒

以满卷形式提供， 的 FK 系列铝电解 器是 FC 系列的微型型号，相比 FC 系列降低了 40-60% 的阻抗值。 这些电解电容器具有长达 5000 小时的长使用寿命，且符合 AEC-Q200 标准，适用于汽车应用。 带有 A

.

后缀的部件号可耐受较高的回流温度，用于延长使用寿命。

欧时:
Panasonic 铝电解电容器 FK SMD 系列 25V dc 10μF 表面安装器件 EEEFK1E100R, ±20%容差

立创商城:
10uF ±20% 25V

e络盟:
铝电解电容, 表面贴装, Radial Can - SMD, 10 µF, 25 V, FK 系列, 2000 hours @ 105°C

艾睿:
Using this electrolytic EEE-FK1E100R aluminum capacitor from Panasonic in your electronic circuit you&s;ll be able to generate high heat for a given current level due to its relatively high equivalent series resistance. It can withstand a voltage of 25 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. Its leakage current is 3@2Min μA. Its capacitance value is 10uF. This product is 5.8 mm tall with a diameter of 4 mm. It has a tolerance of 20%.

Allied Electronics:
Capacitor; Aluminum Electrolytic; Ecap 10uF 25V B Case

安富利:
Cap Aluminum 10uF 25V 20% 4 X 5.8mm SMD 90mA 2000 hr 105°C T/R

Verical:
Cap Aluminum Lytic 10uF 25V 20% 4 X 5.8mm SMD 90mA 2000h 105C Automotive T/R

儒卓力:
**V-FK 10uF 25V 20% 4x6 **
