ESD 保护器,On Semiconductor### 瞬态电压抑制器,On Semiconductor
汽车 ESD 保护器,
一系列单/双线路瞬态电压抑制器 TVS,设计用于为汽车应用中的敏感数字信号线路提供 ESD 保护。所有均符合 AEC-Q101 标准。
### 标准
AEC-Q101
得捷:
TRANS VOLTAGE SUPPRESSOR DIODE,
欧时:
TVS 二极管 ON Semiconductor ESD7M5.0DT5G 单向, 0.15W, 10.4V, 3针 SOT-723封装
艾睿:
Install this tvs ESD7M5.0DT5G ESD protection device from ON Semiconductor to prevent future damage to your electronic equipment from electrostatic discharge. This ESD diode has a maximum ESD protection device voltage of ±10@Contact Disc kV. This device&s;s maximum clamping voltage is 10.4 V. This ESD diode has an operating temperature range of -55 °C to 125 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. It is made in a dual common anode|single configuration. Its capacitance value is 2.5|1.25 pF.
Allied Electronics:
ESD7M5.0DT5G, Dual TVS Diode, 150mW, 3-Pin SOT-723
安富利:
ESD Suppressor TVS ±10KV 3-Pin SOT-723 T/R
Chip1Stop:
ESD Suppressor TVS ±10kV Automotive 3-Pin SOT-723 T/R
Verical:
ESD Suppressor Diode TVS Uni-Dir/Bi-Dir 5V 3-Pin SOT-723 T/R
力源芯城:
二线单向超低电容
Win Source:
TVS DIODE 5VWM 10.4VC SOT723
电容 2.5 pF
无卤素状态 Halogen Free
击穿电压 5.4 V
通道数 2
耗散功率 0.15 W
钳位电压 10.4 V
最大反向电压(Vrrm) 5V
测试电流 1 mA
脉冲峰值功率 0.15 W
最小反向击穿电压 5.4 V
最大反向漏电流(Ir) 1uA
工作温度Max 125 ℃
工作温度Min -55 ℃
耗散功率Max 150 mW
安装方式 Surface Mount
引脚数 3
封装 SOT-723-3
长度 1.25 mm
宽度 0.85 mm
高度 0.55 mm
封装 SOT-723-3
工作温度 -55℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 8000
制造应用 USB2.0 high speed and antenna line applications, 汽车级
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ESD7M5.0DT5G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
ESD7L5.0DT5G 安森美 | 类似代替 | ESD7M5.0DT5G和ESD7L5.0DT5G的区别 |
SESD7L5.0DT5G 安森美 | 功能相似 | ESD7M5.0DT5G和SESD7L5.0DT5G的区别 |
