UNITED CHEMI-CON EMVY160ADA221MF80G 铝电解电容, 220uF 16V SMD
220µF 16V Aluminum Electrolytic Capacitors Radial, Can - SMD 1000 Hrs @ 105°C
得捷:
CAP ALUM 220UF 20% 16V SMD
e络盟:
铝电解电容, 220uF 16V SMD
艾睿:
Cap Aluminum Lytic 220uF 16V 20% 6.3 X 7.7mm SMD 280mA 1000h 105°C Automotive T/R
Verical:
Cap Aluminum Lytic 220uF 16V 20% 6.3 X 7.7mm SMD 280mA 1000h 105C Automotive T/R
Newark:
# UNITED CHEMI-CON EMVY160ADA221MF80G SMD Aluminum Electrolytic Capacitor, Alchip™, Radial Can - SMD, 220 µF, 16 V, 0.34 ohm, MVY Series
MASTER:
Cap Aluminum Lytic 220uF 16V 20% 6.3 X 7.7mm SMD 280mA 1000h 105°C Automotive T/R
Electro Sonic:
Cap Aluminum Lytic 220uF 16V 20% 6.3 X 7.7mm SMD 280mA 1000h 105°C Automotive T/R
Win Source:
CAP ALUM 220UF 20% 16V SMD / 220 µF 16 V Aluminum Electrolytic Capacitors Radial, Can - SMD 1000 Hrs @ 105°C
额定电压DC 16.0 V
电容 220 µF
等效串联电阻ESR 0.34 Ω
容差 ±20 %
纹波电流 280 mA
纹波电流高频 140mA @120Hz
纹波电流低频 280mA @100kHz
工作温度Max 105 ℃
工作温度Min -55 ℃
额定电压 16 V
安装方式 Surface Mount
引脚数 2
封装 SMD
长度 7.70 mm
宽度 6.60 mm
高度 7.7 mm
直径 6.30 mm
封装 SMD
介质材料 Aluminum Electrolytic
工作温度 -55℃ ~ 105℃
产品生命周期 Active
包装方式 Cut Tape CT
寿命（小时） 1000h @105℃
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
HTS代码 8532220020
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
EMVY160ADA221MF80G Chemi-Con 贵弥功 | 当前型号 | 当前型号 |
EMZA160ADA221MF80G 贵弥功 | 完全替代 | EMVY160ADA221MF80G和EMZA160ADA221MF80G的区别 |
EEEFK1C221XP 松下 | 完全替代 | EMVY160ADA221MF80G和EEEFK1C221XP的区别 |
MVY16VC221MF80TP 贵弥功 | 完全替代 | EMVY160ADA221MF80G和MVY16VC221MF80TP的区别 |
