EL2480CS-T7

为250MHz / 3毫安电流模式反馈放大器 250MHz/3mA Current Mode Feedback Amplifier

250MHz/3mA Current Mode Feedback Amplifier

The EL2480 is a quad current-feedback operational amplifier which achieves a -3dB bandwidthof 250MHz at a gain of +1 while consuming only 3mA of supply current per amplifier. It will operate with dual supplies ranging from ±1.5V to ±6V, or from single supplies ranging from +3V to +12V. In spite of its low supply current, the EL2480 can output 55mA while swinging to ±4V on ±5V supplies. These attributes make the EL2480 an excellent choice for low power and/or low voltage

cable-driver, HDSL, or RGB applications.

Features

• Quad topology

• 3mA supply current per amplifier

• 250MHz -3dB bandwidth

• Low cost

• Single- and dual-supply operation down to ±1.5V

• 0.05%/0.05° diff. gain/diff. phase into 150Ω

• 1200V/µs slew rate

• Large output drive current - 55mA

• Also available with disable in triple

• Pb-Free plus Anneal available RoHS compliant

Applications

• Low power/battery applications

• HDSL amplifiers

• Video amplifiers

• Cable drivers

• RGB amplifiers

• Test equipment amplifiers

• Current to voltage converters
