EL5423CL

12MHz的4 ， 8 ， 10及12通道，轨到轨输入输出缓冲器 12MHz 4, 8, 10 & 12 Channel Rail-to-Rail Input-Output Buffers

The EL5123, EL5223, EL5323, and EL5423 are low power, high voltage rail-to-rail input/output buffers designed

primarily for use in reference voltage buffering applications for TFT-LCDs. They are available in quad EL5123, octal EL5223, 10-channel EL5323, and 12-channel EL5423 topologies. All buffers feature a -3dB bandwidth of 12MHz and operate from just 600µA per buffer. This family also features fast slewing and settling times, as well as a continuous output drive capability of 30mA sink and source.

Features

• 12MHz -3dB bandwidth

• Supply voltage = 4.5V to 16.5V

• Low supply current per buffer = 600µA

• High slew rate = 15V/µs

• Rail-to-rail input/output swing

• Ultra-small packages

• Pb-free available RoHS compliant

Applications

• TFT-LCD drive circuits

• Electronics notebooks

• Electronic games

• Touch-screen displays

• Personal communication devices

• Personal digital assistants PDA

• Portable instrumentation

• Sampling ADC amplifiers

• Wireless LANs

• Office automation

• Active filters

• ADC/DAC buffers
