EEEFP1V151AP

PANASONIC ELECTRONIC COMPONENTS  EEEFP1V151AP  铝电解电容, 表面贴装, AEC-Q200 FP系列, 150 µF, 35 V, Radial Can - SMD, 8 mm, 0.08 ohm

FP 系列

FP 系列 V 型电解器在 +105°C 条件下的耐受性可达 2000 小时。 具有低 ESR，这些表面安装电容器比 Panasonic FK 系列低 30% 到 50%。 这些铝电容器可耐受高温无铅回流，可延长使用时间。

符合 AEC-Q200 规格（可能略有偏差）

长寿命

高可靠性

高波纹电流

低阻抗

表面安装

欧时:
Panasonic 铝电解电容器 FP SMD 系列 35V dc 150μF 表面安装器件 EEEFP1V151AP, ±20%容差

立创商城:
150uF ±20% 35V

e络盟:
铝电解电容, 表面贴装, Radial Can - SMD, 150 µF, 35 V, 0.08 ohm, FP 系列, 2000 hours @ 105°C

艾睿:
By using pure aluminum foil in the anode, this electrolytic EEE-FP1V151AP aluminum capacitor from Panasonic can easily filter low frequencies. It can withstand a voltage of 35 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. This product is 10.2 mm tall with a diameter of 8 mm. Its capacitance value is 150uF. Its leakage current is 52.5@2Min μA. It has a tolerance of 20%.

Allied Electronics:
Capacitor; Aluminum Electrolytic; Ecap SMT 150uF 35V F Case

安富利:
Cap Aluminum 150uF 35V 20% 8 X 10.2mm SMD 0.08 Ohm 850mA 2000 hr 105°C Embossed T/R

TME:
Capacitor: electrolytic; low impedance; 150uF; 35VDC; Case: F; FP

儒卓力:
**V-FP 150uF 35V 20% 8x10 **
