EEUFR1H821L

105°C

FR 系列 35 V 到 63 V

FR 系列 A 型电解器具有低 ESR（符合 FM 系列）。 这些径向电容器在 +105°C 时的耐受性可达 5000 小时至 10000 小时（取决于盒体尺寸）。

高可靠性

长寿命

低阻抗

高波纹电流

欧时:
Capacitor Al FR 820uF 50V L 12.5x35

立创商城:
EEUFR1H821L

艾睿:
The pure aluminum anode on the electrolytic EEU-FR1H821L electrolytic capacitor, designed from Panasonic, is the solution to your signal filtering needs. It can withstand a voltage of 50 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. Its leakage current is 410@2Min μA. This part has a lead diameter of 0.8 mm and a pitch of 5 mm. Its capacitance value is 820uF. The EEU-FR1H821L aluminum electrolytic capacitor has a radial termination style. This product is 35 mm tall with a diameter of 12.5 mm. It has a tolerance of 20%.

安富利:
Cap Aluminum 820uF 50V 20% 12.5 X 35mm Radial 5mm 3270mA 10000h 105°C Bulk

Verical:
Cap Aluminum Lytic 820uF 50V 20% 12.5 X 35mm Radial 5mm 3270mA 10000h 105C Bulk
