ECA1JHG222

PANASONIC ELECTRONIC COMPONENTS  ECA1JHG222  铝电解电容, AEC-Q200 NHG系列, 2200 µF, ± 20%, 63 V, 18 mm, 径向引线

NHG 系列

NHG A 型电解器在 +105°C 条件下耐受性可达 1000 至 2000 小时（取决于盒体尺寸。 这些径向电容器与 NHE 系列相比，提供更紧凑的解决方案。

径向引线型

高可靠性

长寿命

低阻抗

高波纹电流

欧时:
Panasonic 铝电解电容器 NHG 系列 63V dc 2200μF 通孔 ECA1JHG222, ±20%容差, 最高+105°C

艾睿:
Do you need something that can let through high frequencies and filter out low frequencies? The electrolytic ECA-1JHG222 electrolytic capacitor from Panasonic is for you. It can withstand a voltage of 63 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. The ECA-1JHG222 aluminum electrolytic capacitor has a radial termination style. Its leakage current is 1386@2Min μA. This product is 35.5 mm tall with a diameter of 18 mm. It has a tolerance of 20%. This part has a lead diameter of 0.8 mm and a pitch of 7.5 mm. Its capacitance value is 2200uF.

安富利:
Cap Aluminum 2200uF 63V 20% 18 X 35.5mm Radial 7.5mm 1610mA 2000h 105°C Bulk

Verical:
Cap Aluminum 2200uF 63V 20% 18 X 35.5mm Radial 7.5mm 1610mA 2000 hr Bulk
