100uF ±20% 400V 900mA Φ25mm
**Kemet ELH Series**
Kemet ELH series aluminum electrolytic snap-in capacitors are designed with snap-lock terminals for printed circuit board mounting. The ELH series has an aluminum case with an insulated sleeve and safety vent at the bottom. Typical applications include general purpose power electronics, UPS, SMPS and battery chargers.
得捷:
CAP ALUM 100UF 20% 400V SNAP
立创商城:
100uF ±20% 400V
贸泽:
Aluminum Electrolytic Capacitors - Snap In 100uF 400V 20% 85C Snap in 25x25
艾睿:
Cap Aluminum Lytic 100uF 400V 20% 25 X 25mm Snap-In 10mm 900mA 2000h 85°C Bulk
Allied Electronics:
Capacitor; Al Electrolytic; Cap 100 uF; Tol 20%; Vol-Rtg 400 VDC; Snap-In; 25X25 mm
安富利:
Cap Aluminum 100uF 400V 20% 25 X 25mm 10mm 900mA 2000 hr 85°C Bulk
额定电压DC 400 V
电容 100 µF
等效串联电阻ESR 592mΩ @20kHz
容差 ±20 %
产品系列 ELH
测试频率 120 Hz
纹波电流 900 mA
工作温度Max 85 ℃
工作温度Min -25 ℃
额定电压 400 V
安装方式 Through Hole
引脚数 2
封装 Radial, CAN
长度 25 mm
高度 25 mm
直径 Φ25mm
封装 Radial, CAN
工作温度 -25℃ ~ 85℃
产品生命周期 Active
包装方式 Bulk
寿命（小时） 2000h @85℃
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
ELH107M400AR1AA KEMET Corporation 基美 | 当前型号 | 当前型号 |
NRLM101M400V25X25F NIC | 功能相似 | ELH107M400AR1AA和NRLM101M400V25X25F的区别 |
ECOS2GP101CA 松下 | 功能相似 | ELH107M400AR1AA和ECOS2GP101CA的区别 |
LH400M0100BPF-2525 国巨 | 功能相似 | ELH107M400AR1AA和LH400M0100BPF-2525的区别 |
