EKMS201VSN152MR40S

Cap Aluminum Lytic 1500uF 200V 20% 30 X 40mm Snap-In 10mm 3260mA 3000H 105℃ Bulk

1500 µF 200 V 铝电解器 径向，Can - 卡入式 - 105°C 时为 3000 小时

艾睿:
This electrolytic EKMS201VSN152MR40S aluminum capacitor from United Chemi-con has a relatively high ESR meaning that it easily generates high heat for a given current level. It can withstand a voltage of 200 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. This product is 40 mm tall with a diameter of 30 mm. The EKMS201VSN152MR40S aluminum electrolytic capacitor has a snap-in termination style. This part has a lead diameter of 1 mm and a pitch of 10 mm. Its leakage current is 1643.17@5Min μA. Its capacitance value is 1500uF. It has a tolerance of 20%.
