PANASONIC ELECTRONIC COMPONENTS ERJ-8ENF4020V SMD Chip Resistor, Thick Film, 402Ω, 200V, 1206 [3216 Metric], 0.25W1/4W, ± 1%, ERJ8E Series
Res Thick Film 1206 402 Ohm 1% 0.25W1/4W ±100ppm/°C Pad SMD Automotive T/R
得捷:
RES SMD 402 OHM 1% 1/4W 1206
贸泽:
Thick Film Resistors - SMD 1206 402ohms 1% AEC-Q200
艾睿:
This is a ERJ-8ENF4020V fixed single surface-mount resistor from Panasonic. This product has a resistance value of 402 Ohm. This dependable part has a power rating of 0.25 1/4 W. Its temperature coefficient is ±100 ppm/°C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This product is 3.2 mm long, 0.6 mm tall and 1.6 mm deep. It has a tolerance of 1%. This device utilizes thick film technology. This part has an operating temperature of -55 to 155 °C.
立创商城:
402Ω ±1% 250mW
Verical:
Res Thick Film 1206 402 Ohm 1% 0.25W1/4W ±100ppm/C Molded SMD Automotive T/R
Newark:
# PANASONIC ELECTRONIC COMPONENTS ERJ-8ENF4020V SMD Chip Resistor, Thick Film, 402 ohm, 200 V, 1206 [3216 Metric], 250 mW, ± 1%, ERJ8E Series
MASTER:
Res Thick Film 1206 402 Ohm 1% 0.25W1/4W ±100ppm/°C Pad SMD Automotive T/R
Online Components:
Res Thick Film 1206 402 Ohm 1% 0.25W1/4W ±100ppm/°C Pad SMD Automotive T/R
Electro Sonic:
Res Thick Film 1206 402 Ohm 1% 0.25W1/4W ±100ppm/°C Pad SMD Automotive T/R
额定电压DC 200 V
容差 ±1 %
额定功率 0.25 W
电阻 402 Ω
阻值偏差 ±1 %
工作温度Max 155 ℃
工作温度Min -55 ℃
额定电压 200 V
安装方式 Surface Mount
封装公制 3216
封装 1206
长度 3.2 mm
宽度 1.6 mm
高度 0.6 mm
封装公制 3216
封装 1206
工作温度 -55℃ ~ 155℃
温度系数 ±100 ppm/℃
产品生命周期 Unknown
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
ECCN代码 EAR99
HTS代码 8533210030
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ERJ-8ENF4020V Panasonic 松下 | 当前型号 | 当前型号 |
CRCW1206402RFKEA 威世 | 类似代替 | ERJ-8ENF4020V和CRCW1206402RFKEA的区别 |
RK73H2BTTD4020F KOA Speer | 类似代替 | ERJ-8ENF4020V和RK73H2BTTD4020F的区别 |
NRC12F4020TRF NIC | 类似代替 | ERJ-8ENF4020V和NRC12F4020TRF的区别 |
