Res Thick Film Array 2.2KΩ 5% 200ppm/℃ ISOL Molded 8Pin 12064 X 0603 Concave SMD T/R
Res Thick Film Array 2.2K Ohm 5% ±200ppm/°C ISOL Molded 8-Pin 12064 X 0603 Concave SMD T/R
立创商城:
2.2kΩ ±5%
得捷:
RES ARRAY 4 RES 2.2K OHM 1206
艾睿:
Looking to save space and power in your circuit design? The EXB-V8V222JV resistor array from Panasonic gives you a solution by combining multiple resistors into a single chip. This dependable part has a power rating per resistor of 0.063 1/16 W. This product&s;s 4 resistors have a value of 2.2K Ohm. Its temperature coefficient is ±200 ppm/°C. It has 8 terminals. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This product&s;s terminal pitch is 0.8 mm. This device utilizes thick film technology. This product is 3.2 mm long, 0.6 mm tall and 1.6 mm deep. This part has an operating temperature of -55 to 125 °C. The EXB-V8V222JV part has a concave termination style. It has a tolerance of 5%.
Verical:
Res Thick Film Array 2.2K Ohm 5% ±200ppm/C ISOL Molded 8-Pin 12064 X 0603 Concave SMD T/R
Newark:
# PANASONIC ELECTRONIC COMPONENTS EXB-V8V222JV Fixed Network Resistor, Isolated, 2.2 kohm, 50 V, 4 Elements, Isolated, 0603 [1608 Metric], 63 mW
MASTER:
Res Thick Film Array 2.2K Ohm 5% ±200ppm/°C ISOL 8-Pin 12064 X 0603 Concave SMD T/R
Online Components:
Res Thick Film Array 2.2K Ohm 5% ±200ppm/°C ISOL Molded 8-Pin 12064 X 0603 Concave SMD T/R
Electro Sonic:
Res Thick Film Array 2.2K Ohm 5% ±200ppm/°C ISOL 8-Pin 12064 X 0603 Concave SMD T/R
触点数 8
额定电压DC 50.0 V
容差 ±5 %
电阻 2.2 KΩ
阻值偏差 ±5 %
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
引脚数 8
封装公制 1608
封装 1206
长度 3.20 mm
宽度 1.60 mm
高度 0.6 mm
封装公制 1608
封装 1206
厚度 600 µm
工作温度 -55℃ ~ 125℃
温度系数 ±200 ppm/℃
产品生命周期 Unknown
包装方式 Tape & Reel TR
制造应用 -
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8533210020
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
EXB-V8V222JV Panasonic 松下 | 当前型号 | 当前型号 |
CRB3A4E222JT 艾维克斯 | 完全替代 | EXB-V8V222JV和CRB3A4E222JT的区别 |
CRC3A4E222JT 艾维克斯 | 完全替代 | EXB-V8V222JV和CRC3A4E222JT的区别 |
