PANASONIC ELECTRONIC COMPONENTS ERA-6AED682V 薄膜片式电阻, 6.8KΩ, 1/8W, 0.5%, 0805, SMD
Res Thin Film 0805 6.8K Ohm 0.5% 0.125W1/8W ±25ppm/°C Pad SMD Automotive T/R
立创商城:
6.8kΩ ±0.5% 125mW
得捷:
RES 6.8K OHM 0.5% 1/8W 0805
e络盟:
PANASONIC ELECTRONIC COMPONENTS ERA-6AED682V 薄膜片式电阻, 6.8KΩ, 1/8W, 0.5%, 0805, SMD
艾睿:
This is a ERA-6AED682V fixed single surface-mount resistor from Panasonic. This dependable part has a power rating of 0.125 1/8 W. This product has a resistance value of 6.8K Ohm. Its temperature coefficient is ±25 ppm/°C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. It has a tolerance of 0.5%. This device utilizes thin film technology. This product is 2 mm long, 0.5 mm tall and 1.25 mm deep. This part has an operating temperature of -55 to 155 °C.
Newark:
# PANASONIC ELECTRONIC COMPONENTS ERA-6AED682V SMD Chip Resistor, Thin Film, 6.8 kohm, 100 V, 0805 [2012 Metric], 125 mW, ± 0.5%, ERA Series
MASTER:
Res Thin Film 0805 6.8K Ohm 0.5% 0.125W1/8W ±25ppm/°C Pad SMD Automotive T/R
Online Components:
Res Thin Film 0805 6.8K Ohm 0.5% 0.125W1/8W ±25ppm/°C Pad SMD Automotive T/R
Electro Sonic:
Res Thin Film 0805 6.8K Ohm 0.5% 0.125W1/8W ±25ppm/°C Pad SMD Automotive T/R
额定电压DC 100 V
容差 ±0.5 %
额定功率 0.125 W
电阻 6.8 kΩ
阻值偏差 ±0.5 %
工作温度Max 155 ℃
工作温度Min -55 ℃
额定电压 100 V
安装方式 Surface Mount
封装公制 2012
封装 0805
长度 2 mm
宽度 1.25 mm
高度 0.5 mm
封装公制 2012
封装 0805
工作温度 -55℃ ~ 155℃
温度系数 ±25 ppm/℃
产品生命周期 Unknown
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8533210040
