铝电解电容器 - 径向引线型 Al Lytic Cap Radial NHG Series 105C
This electrolytic aluminum capacitor from has a relatively high ESR meaning that it easily generates high heat for a given current level. It can withstand a voltage of 200 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. Its capacitance value is 22uF. It has a tolerance of 20%. This part has a lead diameter of 0.6 mm and a pitch of 5 mm. Its leakage current is 274@2Min μA. This product is 20 mm tall with a diameter of 10 mm. The ECA-2DHG220 aluminum electrolytic capacitor has a radial termination style.
额定电压DC 200 V
电容 22 µF
容差 ±20 %
纹波电流 140 mA
工作温度Max 105 ℃
工作温度Min -25 ℃
额定电压 200 V
安装方式 Through Hole
引脚数 2
封装 Radial, CAN
引脚间距 5 mm
长度 20 mm
高度 20 mm
直径 10.0 mm
封装 Radial, CAN
引脚间距 5 mm
介质材料 Aluminum Electrolytic
工作温度 -25℃ ~ 105℃
产品生命周期 Unknown
包装方式 Bulk
寿命（小时） 2000 h
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
ECA-2DHG220 Panasonic 松下 | 当前型号 | 当前型号 |
UVZ2D220MPD 尼吉康 | 功能相似 | ECA-2DHG220和UVZ2D220MPD的区别 |
UPW2D220MPD 尼吉康 | 功能相似 | ECA-2DHG220和UPW2D220MPD的区别 |
ECA-2CHG220B 松下 | 功能相似 | ECA-2DHG220和ECA-2CHG220B的区别 |
