ERJ3EKF7152V

PANASONIC ELECTRONIC COMPONENTS  ERJ3EKF7152V  片式电阻器, 表面贴装, 厚膜, AEC-Q200 ERJ系列, 71.5 kohm, 75 V, 0603 [1608公制], 100 mW, ± 1%

0603 格式器，ERJ3EK 系列 - 1% 35.7Ω-196Ω

ERJ 3E 精密厚膜片式电阻器是紧凑、轻型解决方案。 这些片式电阻器由三层电极、金属釉厚膜电阻元件构成，非常可靠。 ERJ 3E 系列具有 ±1% 的低电阻容差，与自动贴片机兼容。 这些片式电阻器具有 AEC-Q200 资格，特别适用于汽车应用。

### 认可

IEC 60115-8，JIS C 5201-8，EIAJ RC-2134B

立创商城:
71.5kΩ ±1% 100mW

欧时:
Panasonic ERJ 系列 0.1W 71.5kΩ 精密厚膜SMD 电阻器 ERJ3EKF7152V, ±1%, ±100ppm/°C, 0603 封装

e络盟:
SMD片式电阻, 厚膜, 0603 [1608公制], 71.5 kohm, ERJ3E 系列, 75 V, 厚膜, 100 mW

艾睿:
The ERJ-3EKF7152V fixed single surface-mount resistor from Panasonic makes it easy to add resistors to your circuit board. This part has a power rating of 0.1 1/10 W. This product has a resistance value of 71.5K Ohm. Its temperature coefficient is ±100 ppm/°C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This product is 1.6 mm long, 0.45 mm tall and 0.8 mm deep. It has a tolerance of 1%. This part has an operating temperature of -55 to 155 °C. This device is made with thick film technology.

安富利:
Res Thick Film 0603 71.5K Ohm 1% 1/10W ±100ppm/°C Molded SMD SMD Punched Carrier T/R

Verical:
Res Thick Film 0603 71.5K Ohm 1% 1/10W ±100ppm/°C SMD Punched Carrier T/R

Newark:
# PANASONIC ELECTRONIC COMPONENTS  ERJ3EKF7152V  Surface Mount Thick Film Resistor, AEC-Q200 ERJ Series, 71.5 kohm, 100 mW, - 1%, 75 V
