EVM1DSX30B52

4mm贴片微调电位器（陶瓷，开架式 EVM1DSX30B52 500Ω 4X4-500Ω

值Resistance | 500Ω/Ohm \---|--- 额定功率Power| 0.2w,1/5w 容差Tolerance| ±25% 温度系数Temperature Coefficient| ±250 ppm/°C 圈数Number of Turns| 单圈 Single 调节类型Adjustment Type| 顶部调节 Top Adjustment 端子类型Termination Style| J引线 J Lead Description & Applications| ● 4 mm Square SMT Trimmer Potentiometers Cermet, Open Frame Type ■ Features ● 4 mm square series for refl ow soldering ● Both sides adjust type EVM1U ● High reliability realized by cermet element ● Ex cel lent mountability ● Conforms to JIS C5260-1:1999 ■ Recommended Applications ● Audio/visual, offi ce, and communication equipment ● General electronic equipment 描述与应用| ●4mm贴片微调（陶瓷，开架式） ■特点 ●4mm的回流焊接系列 ●双方调整型（EVM1U） ●高可靠性实现了金属陶瓷元件 ●EX CEL借给安装性 ●符合JIS电子设备用电位计-1：1999 ■推荐应用 ●音频/视觉，OFFI CE和通信设备 ●一般电子设备
