GENERAL ELECTRIC IEC CONTROLS EP101ULD06 Thermal Magnetic Circuit Breaker, EP100 Series, 277VAC, 50VDC, 6A, 1Pole, DIN Rail
The ElfaPlus- .
- with UL approval cover all needs that a GLOBAL OEM could have in its equipment:
* Line Protection: Branch Circuit Breakers and Supplementary Protection
* People Protection: UL Recognized GPDs
* Add on Devices: UL Recognized Add on devices.
* UL Busbars to connect Branch Circuit Breakers and supplementary protection
* Equipment Protection: A complete range of SPDs adapted to NEMA electrical nets and new UL Photovoltaic SPDs range.
* Energy Efficiency: Power Analyzers UL Listed
* * *
Features:
* * *
New modular compact standard 35mm DIN-rail mount UL MCBs
Complete range of UL489 and UL1077 Miniature Circuit Breakers up to 63A
Standard rating of 10kA at 480Y/277 Vac and 240/120Vac
Suitable for branch circuit device protection
Module width of only 0.71 in 18 mm per pole
Contact position indication red/green
Possibility for locking the toggle in OFF position
Complete range of UL1077 Auxiliaries, Shunt trips and undervoltage bifunctional wires & bars strong terminals. UL489 busbars available in the range.
The UL MCB range is completed with Ground fault devices, Surge protective devices and Net analyzers.
