2.2mF ±20% 63V 2300mA Φ25.4mm
2200µF 63V Aluminum Electrolytic Capacitors Radial, Can - Snap-In 113mOhm @ 120Hz 2000 Hrs @ 85°C
得捷:
CAP ALUM 2200UF 20% 63V SNAP
艾睿:
This electrolytic ESMH630VNN222MQ25T aluminum capacitor from United Chemi-con has a relatively high ESR meaning that it easily generates high heat for a given current level. It can withstand a voltage of 63 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 85 °C. Its leakage current is 2772@5Min μA. This product is 25 mm tall with a diameter of 25.4 mm. The ESMH630VNN222MQ25T aluminum electrolytic capacitor has a snap-in termination style. It has a tolerance of 20%. This part has a lead diameter of 1 mm and a pitch of 10 mm. Its capacitance value is 2200uF.
Chip1Stop:
Cap Aluminum Lytic 2200uF 63V 20% 25.4 X 25mm Snap-In 10mm 0.113 Ohm 2300mA 2000h 85C Bulk
Verical:
Cap Aluminum Lytic 2200uF 63V 20% 25.4 X 25mm Snap-In 10mm 0.113 Ohm 2300mA 2000h 85C
Electro Sonic:
Cap Aluminum Lytic 2200uF 63V 20% 25.4 X 25mm Snap-In 10mm 0.113 Ohm 2300mA 2000h 85°C
