ESMG160ELL222MK20S

UNITED CHEMI-CON  ESMG160ELL222MK20S  铝电解电容； 2200uF

铝电解器 径向，Can - 85°C 时为 2000 小时

得捷:
CAP ALUM 2200UF 20% 16V RADIAL

e络盟:
铝电解电容； 2200uF

艾睿:
Using the aluminum anode based electrolytic ESMG160ELL222MK20S electrolytic capacitor, developed by United Chemi-con, you can filter out lower signal frequencies. It can withstand a voltage of 16 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 85 °C. This product is 20 mm tall with a diameter of 12.5 mm. It has a tolerance of 20%. Its capacitance value is 2200uF. Its leakage current is 1056@1Min μA. The ESMG160ELL222MK20S aluminum electrolytic capacitor has a radial termination style. This part has a lead diameter of 0.6 mm and a pitch of 5 mm.

Chip1Stop:
Cap Aluminum 2200uF 16V 20% 12.5 X 20mm Radial 5mm 1295mA 2000h 85℃ Bulk

Verical:
Cap Aluminum Lytic 2200uF 16V 20% 12.5 X 20mm Radial 5mm 1295mA 2000h 85C Bulk

Newark:
# UNITED CHEMI-CON  ESMG160ELL222MK20S  Electrolytic Capacitor, Miniature, 2200 µF, 16 V, SMG Series, ± 20%, Radial Leaded, 12.5 mm

MASTER:
Cap Aluminum Lytic 2200uF 16V 20% 12.5 X 20mm Radial 5mm 1295mA 2000h 85°C Bulk

Electro Sonic:
Cap Aluminum Lytic 2200uF 16V 20% 12.5 X 20mm Radial 5mm 1295mA 2000h 85°C Bulk
