ELXY100ELL222MK25S

UNITED CHEMI-CON  ELXY100ELL222MK25S  铝电解电容, 2200uF, 10V, 径向引线

Cap Aluminum Lytic 2200uF 10V 20% 12.5 X 25mm Radial 5mm 1690mA 7000h 105°C Automotive Bulk

得捷:
CAP ALUM 2200UF 20% 10V RADIAL

e络盟:
铝电解电容, 2200uF, 10V, 径向引线

艾睿:
The pure aluminum anode on the electrolytic ELXY100ELL222MK25S electrolytic capacitor, designed from United Chemi-con, is the solution to your signal filtering needs. It can withstand a voltage of 10 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. The ELXY100ELL222MK25S aluminum electrolytic capacitor has a radial termination style. This product is 25 mm tall with a diameter of 12.5 mm. Its leakage current is 220@2Min μA. It has a tolerance of 20%. This part has a lead diameter of 0.6 mm and a pitch of 5 mm. Its capacitance value is 2200uF.

Chip1Stop:
Cap Aluminum Lytic 2200uF 10V 20% 12.5 X 25mm Radial 5mm 1690mA 7000h 105℃ Bulk

Verical:
Cap Aluminum Lytic 2200uF 10V 20% 12.5 X 25mm Radial 5mm 1690mA 7000h 105C Automotive Bulk

Newark:
# UNITED CHEMI-CON  ELXY100ELL222MK25S  Electrolytic Capacitor, Miniature, 2200 µF, 10 V, LXY Series, ± 20%, Radial Leaded, 12.5 mm

MASTER:
Cap Aluminum Lytic 2200uF 10V 20% 12.5 X 25mm Radial 5mm 1690mA 7000h 105°C Automotive Bulk

Electro Sonic:
Cap Aluminum Lytic 2200uF 10V 20% 12.5 X 25mm Radial 5mm 1690mA 7000h 105°C Automotive Bulk
