NKK SWITCHES FB15ANEP4-FA 按钮开关, 非发光, SPST, 0.1A, 黑色
Series FB momentary pushbuttons utilize a nickel-plated brass bushing, a phenolic resin case and a polyacetal plunger combined to offer a lightweight switch. Self cleaning contacts and epoxy sealed terminals insure long switch life. UL recognized only when ordered with UL mark on switch.
立创商城:
FB15ANEP4-FA
得捷:
SWITCH PUSH SPST-NO 0.4VA 28V
e络盟:
NKK SWITCHES FB15ANEP4-FA 按钮开关, 非发光, SPST, 0.1A, 黑色
艾睿:
Never worry about turning off components or cutting off certain sections of a circuit with this FB15ANEP4-FA push button switch from NKK Switches. It has a SPST configuration. This push switch has an operating temperature range of -10 °C to 70 °C. The FB15ANEP4-FA push switch has a pc turret termination style. This product is 7 mm long, 21.7 mm tall and 7 mm deep. The maximum AC voltage rating is 28 VAC and the maximum DC voltage rating is 28 VDC.
Allied Electronics:
SUBMINIATURE PUSHBUTTON/BUSHING MOUNT
Chip1Stop:
Switch Push Button OFF ON SPST Round Plunger 28VAC 28VDC 0.4VA Momentary Contact PC Turret Panel Mount/Through Hole
Verical:
Switch Push Button OFF ON SPST Round Plunger 28VAC 28VDC 0.4VA Momentary Contact PC Turret Thru-Hole
Newark:
# NKK SWITCHES FB15ANEP4-FA Pushbutton Switch, SPST, Off-On, 28 V, 28 V, 100 mA, Solder
