FKP2J014701I00KSSD

4.7nF ±10% 630V PP 8mm

This pulse film capacitor from Wima is ideal for voltage smoothing, and would make any filter or audio based design better for the smoothest signal. It can withstand a voltage of 630 VDC|250VAC. This part has a maximum operating temperature of 100 °C. This part has a lead diameter of 0.5 mm and a pitch of 5 mm. Its capacitance value is 0.0047uF. This product is 7.2Max mm long, 8Max mm tall and 6.5Max mm deep. The FKP2J014701I00KSSD part has a radial termination style. It has a tolerance of 10%.
