WIMA FKP1T011004C00KSSD 膜电容, FKP1系列, 1000 pF, ± 10%, PP聚丙烯, 1.6 kV
The is a polypropylene PP Film Capacitor with for pulse applications with metal foil electrodes, schoopage contacts, double-sided metallization and self-healing internal series connection for highest current carrying capability in PCM 15 to 37.5mm. The FKP1 series film capacitor has radial leaded tinned wire terminations and UL94V-0 solvent-resistant/flame-retardant plastic case with epoxy resin seal encapsulation.
- .
- Extremely high pulse duty
- .
- Self-healing
- .
- Internal series connection
- .
- Very low dissipation factor
- .
- Negative capacitance change versus temperature
额定电压DC 1.60 kV
电容 1000 pF
容差 ±10 %
产品系列 FKP1
工作温度Max 100 ℃
工作温度Min -55 ℃
额定电压 1.6 kV
安装方式 Through Hole
引脚数 2
封装 Radial, Box
引脚间距 15 mm
长度 18 mm
宽度 6 mm
高度 12.5 mm
封装 Radial, Box
引脚间距 15 mm
材质 PP
介质材料 Polypropylene
工作温度 -55℃ ~ 100℃
产品生命周期 Active
包装方式 Each
制造应用 Power Management, Consumer Electronics, Lighting
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
FKP1T011004C00KSSD WIMA | 当前型号 | 当前型号 |
FKP1T011004C00KMSD WIMA | 功能相似 | FKP1T011004C00KSSD和FKP1T011004C00KMSD的区别 |
