FJX3005RTF

特性•开关电路，逆变器，接口电路，驱动器电路•内置偏置电阻（R1=4.7KΩ，R2=10KΩ）•FJX4005R的补充

集电极-基极反向击穿电压VBRCBO Collector-Base VoltageVCBO| 50V \---|--- 集电极-发射极反向击穿电压VBRCEO Collector-Emitter VoltageVCEO| 50V 集电极连续输出电流IC Collector CurrentIC| 100mA/0.1A 基极输入电阻R1 Input ResistanceR1| 4.7KΩ/Ohm 基极-发射极输入电阻R2 Base-Emitter ResistanceR2| 10KΩ/Ohm 电阻比R1/R2 Resistance Ratio| 0.47 直流电流增益hFE DC Current GainhFE| 30 截止频率fT Transtion FrequencyfT| 250MHz 耗散功率Pc Power Dissipation| 0.2W/200mW Description & Applications| Features • Switching circuit, Inverter, Interface circuit, Driver Circuit • Built in bias Resistor R1=4.7KΩ, R2=10KΩ • Complement to FJX4005R 描述与应用| 特性 •开关电路，逆变器，接口电路，驱动器电路 •内置偏置电阻（R1=4.7KΩ，R2=10KΩ） •FJX4005R的补充
