FECC1602B-NSWBBW-91LE

FORDATA  FECC1602B-NSWBBW-91LE  字母数字液晶屏, 16 x 2, 蓝色底白色字, 3 V, 并行, 英式, 日式, 透射

* Alphanumeric / character LCD module

.

2 lines of 16 characters - 2 x 16 also referred to as 16 x 2

.

Negative mode blue STN material

.

Appearance - white characters on blue background

.

Transmissive technology, generally for indoor applications

.

Chip on board construction COB for easy mounting

.

On board controller SPLC780 or equivalent HD44780 derivative

.

English/Japanese font sets

.

3V logic supply, standard parallel interface

.

Display duty 1/8, Driving bias 1/4

.

White LED backlight

.

Preferred view angle - 6 o"clock

.

-20 to +70°C wide operating temperature range

.

16 way through hole DIL side, left 2x8 connection, 2.54mm pitch

.

Overall max dimensions - 85.0 x 36.0 x 13.5mm

.

Viewing area - 64.5 x 16.4mm

.

5mm character actual dimension 3.00 x 5.23mm
