FTSH-105-02-L-D

SAMTEC FTSH-105-02-L-D Board-To-Board Connector, 1.27mm, 10Contacts, Header, FTSH Series, Solder, 2Rows

The FTSH series from are through hole micro terminal strip headers. It mates with Samtec FFSD, FFTP, CLP and FLE series of connectors. These terminal strip headers are available in end shroud, end shroud with locking clip, end shroud with guide post, end shroud with board lock, ejector shroud and keying shroud option.

.

Available in dual row

.

Pitch spacing is 1.27mm 2 to 50 contacts per row with straight orientation

.

Operating temperature range of -55°C to 125°C

.

Contact material is phosphor bronze

.

Black liquid crystal polymer insulator material

.

Complies with UL E111594 and CSA 090871_0_000 standards

.

10µ" gold plated contacts
