FTSH-107-01-L-DV-K

板至板连接, 1.27 mm, 14 触点, 针座, FTSH Series, 表面安装　, 2 排

Connector Header Surface Mount 14 position 0.050" 1.27mm

欧时:
.050" Micro Terminal Strip

得捷:
CONN HEADER SMD 14POS 1.27MM

艾睿:
Look no further than the unshrouded FTSH-107-01-L-DV-K header connector from Samtec, a great tool to use when board-to-board interconnects is required. This HDR connector&s;s 14 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. It has a straight body orientation. It has a header type gender. Its pitch is 1.27 mm. This device has a maximum current rating of 3.3 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This product is 8.89 mm long, 5.97 mm tall and 5.84 mm deep. This connector has an operating temperature of -55 to 125 °C. FTSH-107-01-L-DV-K is housed in black liquid crystal polymer. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 14 POS 1.27mm Solder ST SMD Tube

Verical:
Conn Unshrouded Header HDR 14 POS 1.27mm Solder ST Top Entry SMD Tube
