FRONT-MC1,5/6-ST-3,81

FRONT-MC1,5/6-ST-3,81图片1
FRONT-MC1,5/6-ST-3,81图片2
FRONT-MC1,5/6-ST-3,81图片3
FRONT-MC1,5/6-ST-3,81概述

PHOENIX CONTACT  FRONT-MC1,5/6-ST-3,81  插拔式接线端子, 6 路, 160 V, 8 A, 3.81 mm, 28 AWG, 16 AWG

The FRONT-MC series Mini plug-in Connector with 3.5/3.81 and 5.08mm pitch. The plugs with front screw connection. It has individual position coding by removing the coding tab and connecting the coding profile to the header. It may be available in versions with and without a screw flange.

.
Screwdriver axis parallel to the conductor axis
.
Generously dimensioned wiring space
.
Higher numbers of positions up to 20-position can be found

In accordance with DIN EN 61984, COMBICON plug-in connectors have no switching power. During designated use, they must not be plugged in or disconnected when carrying voltage or under load.

FRONT-MC1,5/6-ST-3,81中文资料参数规格
技术参数

触点数 6

线规 16.0 AWG

触点电镀 Tin

额定电流 8 A

针脚数 6

额定电压 160 V

封装参数

安装方式 PCB

物理参数

触点材质 Copper

符合标准

RoHS标准 RoHS Compliant

数据手册

在线购买FRONT-MC1,5/6-ST-3,81
型号: FRONT-MC1,5/6-ST-3,81
制造商: Phoenix 菲尼克斯
描述:PHOENIX CONTACT  FRONT-MC1,5/6-ST-3,81  插拔式接线端子, 6 路, 160 V, 8 A, 3.81 mm, 28 AWG, 16 AWG
替代型号FRONT-MC1,5/6-ST-3,81
型号/品牌 代替类型 替代型号对比

FRONT-MC1,5/6-ST-3,81

Phoenix 菲尼克斯

当前型号

当前型号

20020013-D061B01LF

法马通

功能相似

FRONT-MC1,5/6-ST-3,81和20020013-D061B01LF的区别

MC310-38106

Multicomp

功能相似

FRONT-MC1,5/6-ST-3,81和MC310-38106的区别
