FMMT491TA 编带
- 双极 BJT - 单 NPN 60 V 1 A 150MHz 500 mW 表面贴装型 SOT-23-3
得捷:
TRANS NPN 60V 1A SOT23-3
立创商城:
NPN 60V 1A
艾睿:
Add switching and amplifying capabilities to your electronic circuit with this NPN FMMT491TA GP BJT from Diodes Zetex. This bipolar junction transistor&s;s maximum emitter base voltage is 5 V. Its maximum power dissipation is 500 mW. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This bipolar junction transistor has an operating temperature range of -55 °C to 150 °C. It has a maximum collector emitter voltage of 60 V and a maximum emitter base voltage of 5 V.
Allied Electronics:
SMT NPN transistor; FMMT491 1A Ic 5Vce
安富利:
Trans GP BJT NPN 60V 1A 3-Pin SOT-23 T/R
Chip1Stop:
Trans GP BJT NPN 60V 1A 500mW Automotive 3-Pin SOT-23 T/R
Verical:
Trans GP BJT NPN 60V 1A Automotive 3-Pin SOT-23 T/R
儒卓力:
**NPN TRANSISTOR 60V 1A SOT23 **
Win Source:
TRANS NPN 60V 1A SOT23-3
频率 150 MHz
额定电压DC 60.0 V
额定电流 1.00 A
极性 NPN
耗散功率 0.5 W
击穿电压集电极-发射极 60 V
集电极最大允许电流 1A
最小电流放大倍数hFE 100 @500mA, 5V
额定功率Max 500 mW
工作温度Max 150 ℃
工作温度Min -55 ℃
耗散功率Max 500 mW
安装方式 Surface Mount
引脚数 3
封装 SOT-23-3
封装 SOT-23-3
工作温度 -55℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
FMMT491TA Diodes 美台 | 当前型号 | 当前型号 |
FMMT491QTA 美台 | 完全替代 | FMMT491TA和FMMT491QTA的区别 |
FMMT491QTC 美台 | 完全替代 | FMMT491TA和FMMT491QTC的区别 |
DNBT8105-7 美台 | 类似代替 | FMMT491TA和DNBT8105-7的区别 |
