FS820R08A6P2BBPSA1

HybridPACK™ Drive module with EDT2 IGBT and Diode is an automotive qualified power module designed for Hybrid- and Electric Vehicle applications. Find appropriate Automotive EiceDRIVER™.

Summary of Features:

.

Blocking Voltage 750V

.

Low VCEsat

.

Low Switching Losses

.

Low QG and Cres

.

Low Inductive Design

.

Tvj op = 150°C

.

Short-time extended Operation Temperature T vj op = 175°C

Benefits:

.

Compact Design

.

Direct Cooled Base Plate

.

Guiding elements for PCB and cooles assembly

.

Integrated NTC temperature sensor

.

PressFIT Contact Technology

.

RoHS complient
