0603 24pF ±5% 50V C0G
24 pF ±5% 50V 陶瓷器 C0G,NP0 0603(1608 公制)
得捷:
CAP CER 24PF 50V NP0 0603
艾睿:
This GCM1885C1H240JA16D multilayer ceramic capacitor from Murata has so many uses that it even has a standard classification system for all its uses! It can withstand a voltage of 50 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This product is 1.6 mm long, 0.8 mm tall and 0.8 mm deep. Its capacitance value is 24pF. It has a tolerance of 5%.
Verical:
Cap Ceramic 24pF 50V C0G 5% Pad SMD 0603 125C Automotive T/R
额定电压DC 50.0 V
电容 24 PF
容差 ±5 %
电介质特性 C0G/NP0
产品系列 GCM
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 50 V
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.6 mm
宽度 0.8 mm
高度 0.8 mm
封装公制 1608
封装 0603
厚度 0.8 mm
材质 C0G/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Not Recommended
包装方式 Tape & Reel TR
最小包装 4000
制造应用 汽车级
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
GCM1885C1H240JA16D muRata 村田 | 当前型号 | 当前型号 |
C0603C240J5GACTU 基美 | 类似代替 | GCM1885C1H240JA16D和C0603C240J5GACTU的区别 |
GRM1885C1H240JA01D 村田 | 类似代替 | GCM1885C1H240JA16D和GRM1885C1H240JA01D的区别 |
MCH185A240JK 罗姆半导体 | 类似代替 | GCM1885C1H240JA16D和MCH185A240JK的区别 |
