0201 2.7 pF 25 V C0G 0.1 pF 容差 SMD 多层陶瓷电容
2.7pF ±0.1pF 25V Ceramic Capacitor C0G, NP0 0201 0603 Metric
欧时:
MLCC SMD 0201 2.7pF 25V C0G Tol 0.1pF Hi
得捷:
CAP CER 2.7PF 25V C0G/NP0 0201
立创商城:
2.7pF ±0.1pF 25V
贸泽:
Multilayer Ceramic Capacitors MLCC - SMD/SMT 0201 2.7pF 25Volts C0G +/-0.1pF
艾睿:
This GJM0335C1E2R7BB01D multilayer ceramic capacitor from Murata is non-polarized so it may be connected either to positive or to negative voltage. It can withstand a voltage of 25 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This product is 0.6 mm long, 0.3 mm tall and 0.3 mm deep. Its capacitance value is 2.7pF.
安富利:
Cap Ceramic 2.7pF 25V C0G 0.1pF SMD 0201 125°C Paper T/R
Chip1Stop:
Cap Ceramic 2.7pF 25V C0G 0.1pF SMD 0201 125℃ T/R
Verical:
Cap Ceramic 2.7pF 25V C0G 0.1pF Pad SMD 0201 125C T/R
额定电压DC 25 V
绝缘电阻 10 GΩ
电容 2.7 pF
容差 ±0.1 pF
电介质特性 C0G/NP0
产品系列 GJM
工作温度Max 125 ℃
工作温度Min 55 ℃
额定电压 25 V
安装方式 Surface Mount
封装公制 1608
封装 0201
长度 0.6 mm
宽度 0.3 mm
高度 0.3 mm
封装公制 1608
封装 0201
厚度 0.3 mm
材质 C0G/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 15000
制造应用 RF,微波,高频
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
GJM0335C1E2R7BB01D muRata 村田 | 当前型号 | 当前型号 |
GJM0335C1E2R7BB01J 村田 | 完全替代 | GJM0335C1E2R7BB01D和GJM0335C1E2R7BB01J的区别 |
CL03C2R7BA3GNNC 三星 | 功能相似 | GJM0335C1E2R7BB01D和CL03C2R7BA3GNNC的区别 |
C0603C0G1E2R7B030BG 东电化 | 功能相似 | GJM0335C1E2R7BB01D和C0603C0G1E2R7B030BG的区别 |
