0805 2nF ±5% 100V C0G
2000pF ±5% 100V Ceramic Capacitor C0G, NP0 0805 2012 Metric
得捷:
CAP CER 2000PF 100V C0G/NP0 0805
立创商城:
2nF ±5%
艾睿:
This GRM2165C2A202JA01D multilayer ceramic capacitor from Murata has so many uses that it even has a standard classification system for all its uses! It can withstand a voltage of 100 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. It has a tolerance of 5%. This product is 2 mm long, 0.6 mm tall and 1.25 mm deep. Its capacitance value is 0.002uF.
Chip1Stop:
Cap Ceramic 0.002uF 100V C0G 5% SMD 0805 125℃ Paper T/R
Verical:
Cap Ceramic 0.002uF 100V C0G 5% Pad SMD 0805 125C T/R
额定电压DC 100 V
电容 0.002 µF
容差 ±5 %
电介质特性 C0G/NP0
产品系列 GRM
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 100 V
安装方式 Surface Mount
封装公制 2012
封装 0805
长度 2 mm
宽度 1.25 mm
高度 0.6 mm
封装公制 2012
封装 0805
厚度 600 µm
材质 C0G/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 4000
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
GRM2165C2A202JA01D muRata 村田 | 当前型号 | 当前型号 |
GRM2165C1H202JA01D 村田 | 功能相似 | GRM2165C2A202JA01D和GRM2165C1H202JA01D的区别 |
GCM2165C2A202JA16B 村田 | 功能相似 | GRM2165C2A202JA01D和GCM2165C2A202JA16B的区别 |
