Switch Rocker ON None ON DPDT PC Pins Paddle Rocker 0.1A 28VAC 28VDC 0.4VA 50000Cycles
* 0.4VA Logic Level; Straight, Right Angle and Vertical PCB Mount
* Ultra-Thin Rocker Switches
* Rocker and paddle actuators in a variety of colors.
* Dust cover and closely fit housing, actuator, and interior pivot provide protection for contacts.
* Detent mechanism for rocker/paddle is designed for crisp and positive actuation.
* Patented sliding twin crossbar STC mechanism provides unequalled logic-level reliability, and smoother, positive detent actuation.
* Extremely thin size allows for high-density PCB mounting, and makes these switches ideal for handheld equipment.
* Molded-in, epoxy sealed terminals lock out flux and other contaminants.
* .100" X .100" terminal spacing conforms to standard PC board grid spacing for straight and angle
触点电镀 Gold
额定电压DC 28 V
额定电压AC 28 V
绝缘电阻 500 MΩ
排数 2
方向 Right Angle
触点类型 DPDT
易燃性等级 UL 94 V-0
接触电阻 80.0 mΩ
额定电流Max 0.1A @28VAC, 28VDC
工作温度Max 85 ℃
工作温度Min -30 ℃
接触电阻Max 80 mΩ
安装方式 PCB
长度 7.5 mm
高度 5.4 mm
颜色 Gray
触点材质 Phosphor Bronze
工作温度 -30℃ ~ 85℃
产品生命周期 Active
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Contains Lead
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
