0603 5pF ±0.1pF 100V C0G
5pF ±0.1pF 100V Ceramic Capacitor C0G, NP0 0603 1608 Metric
得捷:
CAP CER 5PF 100V C0G/NP0 0603
艾睿:
Use its standard classification system to find out what this GQM1885C2A5R0BB01D multilayer ceramic capacitor from Murata can do for you! It can withstand a voltage of 100 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This product is 1.6 mm long, 0.8 mm tall and 0.8 mm deep. Its capacitance value is 5pF.
额定电压DC 100 V
电容 5 pF
容差 ±0.1 pF
电介质特性 C0G/NP0
产品系列 GQM
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 100 V
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.60 mm
宽度 0.8 mm
高度 0.8 mm
封装公制 1608
封装 0603
厚度 0.8 mm
材质 C0G/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 End of Life
包装方式 Tape & Reel TR
最小包装 4000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
GQM1885C2A5R0BB01D muRata 村田 | 当前型号 | 当前型号 |
GRM1885C2A5R0BA01D 村田 | 类似代替 | GQM1885C2A5R0BB01D和GRM1885C2A5R0BA01D的区别 |
