0805 1.2pF ±0.1pF 250V C0G
1.2pF ±0.1pF 250V Ceramic Capacitor C0G, NP0
立创商城:
1.2pF ±0.1pF 250V
得捷:
CAP CER 1.2PF 250V C0G/NP0 0805
艾睿:
Get more with less with Murata&s;s GQM2195C2E1R2BB12D multilayer ceramic capacitor which uses multiple layers of ceramic and metal to act as dielectric and electrodes. It can withstand a voltage of 250 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. Its capacitance value is 1.2pF. This product is 2 mm long, 0.85 mm tall and 1.25 mm deep.
安富利:
Cap Ceramic 1.2pF 250V C0G 0.1pF SMD 0805 125°C Paper T/R
Chip1Stop:
Cap Ceramic 1.2pF 250V C0G 0.1pF SMD 0805 125℃ T/R
Verical:
Cap Ceramic 1.2pF 250V C0G 0.1pF Pad SMD 0805 125C T/R
额定电压DC 250 V
电容 1.2 pF
容差 ±0.1 pF
电介质特性 C0G/NP0
产品系列 GQM
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 250 V
安装方式 Surface Mount
封装公制 2012
封装 0805
长度 2.00 mm
宽度 1.25 mm
高度 0.85 mm
封装公制 2012
封装 0805
厚度 0.85 mm
材质 C0G/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 4000
制造应用 RF,微波,高频
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
GQM2195C2E1R2BB12D muRata 村田 | 当前型号 | 当前型号 |
ERB21B5C2E1R2BDX1L 村田 | 完全替代 | GQM2195C2E1R2BB12D和ERB21B5C2E1R2BDX1L的区别 |
GQM2195C2A1R2BB01D 村田 | 功能相似 | GQM2195C2E1R2BB12D和GQM2195C2A1R2BB01D的区别 |
