0201 1 pF 25 V C0G 0.25 pF 容差 多层陶瓷电容
MLCC-多层陶瓷器
立创商城:
1pF ±0.25pF 25V
得捷:
CAP CER 1PF 25V C0G/NP0 0201
艾睿:
Since this GJM0335C1E1R0CB01D multilayer ceramic capacitor from Murata has multiple layers of dielectric and electrodes, you&s;ll be getting high stability and low losses for resonant circuit applications. It can withstand a voltage of 25 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This product is 0.6 mm long, 0.3 mm tall and 0.3 mm deep. Its capacitance value is 1pF.
安富利:
Cap Ceramic 1pF 25V C0G 0.25pF SMD 0201 125°C Paper T/R
Verical:
Cap Ceramic 1pF 25V C0G 0.25pF Pad SMD 0201 125C T/R
额定电压DC 25.0 V
电容 1 pF
容差 ±0.25 pF
电介质特性 C0G/NP0
产品系列 GJM
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 25 V
安装方式 Surface Mount
封装 0201
长度 0.6 mm
宽度 0.3 mm
高度 0.3 mm
封装 0201
厚度 0.3 mm
材质 C0G/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 15000
制造应用 RF,微波,高频
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
GJM0335C1E1R0CB01D muRata 村田 | 当前型号 | 当前型号 |
GRM0335C1E1R0CD01D 村田 | 完全替代 | GJM0335C1E1R0CB01D和GRM0335C1E1R0CD01D的区别 |
C0603C0G1E010C030BA 东电化 | 类似代替 | GJM0335C1E1R0CB01D和C0603C0G1E010C030BA的区别 |
GRM0335C1E1R0CA01D 村田 | 类似代替 | GJM0335C1E1R0CB01D和GRM0335C1E1R0CA01D的区别 |
