Battery Chargers 1Out 13.6V 7.5A 102W
**Features:
* **Portable Power Adapter with Charging Function
* Suitable for Batter Back Up System, Electrical Wheelchair, Trailer or General Consumer Electronics Products
* 3- Pole AC Inlet
* Anderson Output Connector
* Class I Power
* High Efficiency Up to 94%
* Protections: Short Circuit/Overload/Over Voltage/Over Temperature
* Fully Enclosed Plastic Case
* 2 Color LED Indicator for Charging Status
* 2-Year Warranty
**Additional Features:**
* Rated Output Power: 102 W
* Output Voltage: 13.6 VDC
* Output Current: 7.5 A
* Input Voltage Range: 85-264 VAC/120- 370 VDC
* Recommended Battery Capacity: 40-100 Ah
* Efficiency: 86.5%
* Overload: 90-110% Rated Output Power
* Overload Protection Type: Constant Current Limiting Recovers Automatically After Fault Condition is Removed
* Over Voltage: 105-135% Rated Output Voltage
* Over Voltage Protection Type: Shut Down O/P Voltage, Re-Power on to Recover
* Output Cable Length: 4 Ft..
* Mean Time Before Failure: 400.7K Hrs. Min.
输出接口数 1
输出电压 13.6 V
输出电流 7.5 A
输出功率 102 W
输出电流Max 7.5 A
输出功率Max 102 W
额定功率Max 102 W
工作温度Max 70 ℃
工作温度Min -30 ℃
输入电压 85VAC ~ 264VAC, 120VDC ~ 370VDC
封装 120
长度 167 mm
宽度 67 mm
高度 35 mm
封装 120
电缆长度 4 Ft
重量 620 g
工作温度 -30℃ ~ 70℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 无铅
ECCN代码 EAR99
HTS代码 8504409510
