G8P1C4TPDC24BYOMZ

Relay; E-Mech; Power; SPDT; Cur-Rtg 20A NO, NC, 10A NC; Ctrl-V 24DC; PCB Mnt

Power PCB relays ideal for HVAC applications. Available with quick-connect terminals. Meets UL 873 column A spacings up to 300 V. UL Class F coil insulation standard. Coil power of 900 mW.

.

* Contacts Rated:** 30 A SPST-NO, 20/10 A SPDT. PCB, PCB+QC and Flange-Mount version also available in open frame. Flange-Mount version is vented.

** Features**

* Up to 30 Amp Switching Capacity in Compact Package

* Available with Quick-Connect Terminals for Easy Load Connecting

* UL Class F Coil Insulation Standard

* Complies with UL 873 and UL 508 Column A Spacings Up to 300 V

* Minimum 6 kV Impulse Surge Withstand

* Ideal for Home and Industrial Appliances, HVAC Heating, Ventilating, and Air Conditioning, and Many Other Applications

* UL/CSA, VDE Approvals
